KD X2 Key Programmer KEYDIY Remote Maker and Transponder Clone

Description

 KeyDiy KD X2 key programmer which is very popular among locksmiths thanks to its small body and powerful functions.The KD-X2 is more than just a cloner, it is also capable of copying transponders, read and write from / to transponders, execute a frequency test and generate type transponders, all in just a few simple steps.

KEYDIY KD X2 Introduction:

1. Power supply: 2600mAh lithium battery; Charge method: USB 5V/1A
2. With 0.91 inch OLED display screen.
3.  Bluetooth BLE4.0 inside, work with mobile KD APP by bluetooth connection
4. Can work with PC software by USB-B connection, and work with Android phone or tablet by OTG connection.
5. With PS-2 interface for connecting remotes to generate.
6. Three functional shortcut buttons: chip identification, remote identification and frequency detection.
7.  Basic functions as below:

• 1) Wired Generation.
• 2) Wireless Generation.
• 3) Mobile Phone Simulation.
• 4) Garage Door Generation.
• 5) Proximity Key Unlock.
• 6)  Frequency Detection.
• 7) Infrared Detection.
• 8) Access Card Copy.
• 9) Fixed Code Remote Copy
• 10) Online HCS Remote Copy.
• 11) Online Chip Copy ( 96 bit 48chip, 46chip, 4Dchip, Toyota chip etc. )
• 12) Chip Generation.
• 13) Chip Editing.
• 14) Chip Simulation.
• 15) lgnition Coil detection.
• 16) Remote Data Backup.
• 17) Additional Functions Will be Available in Succession.
• 18) Free Activation of 96 Bits 48 Transponder Copy

KEYDIY KD X2 Key programmer Functions details :

Transponder Identification

•  Fixed code ID 11, 12, 13, 33 and 4C
• Philips Crypto 40, 41, 42, 44, 45, 46, 47, 49 and 4A
•  Megamos 48, 48 Canbus
• Texas Crypto 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 6A, 6B, 70, 71, 72, 82, 83, 8C and 8E
• Most smart keys

Transponder Cloning(built-in snoop for ID46 and ID48 cloning)

• 4D/ 4C / 46 / 11 / 12 / 13 / 33 transponder clone
•  ID48 (96 Bit) Only
• Fixed code (T5) – ID 11, 12, 13 & 33 using a carbon T5 chip
•  Texas TX 4C
• Texas Crypto TX/CR 4D
• Philips Crypto PH/CR 46
• Toyota 80 Bit
• Megamos Crypto

Transponder Production:

• ID4D / 60 / Epica60 / 61 / 62 / 63 / 64 / 65 / 66 / 67 / 68 / 69 / 6A / 71 / 72G 4C transponder
•  ID48 type: Seat TP22 / VAG TP23 / Skoda TP24 / Audi TP25 / Seat TA22 / VAG TA23 / Skoda
• TA24 / Audi TA25 / Fiat ID48 / Jetta ID48
• ID46 type: Great Wall (STEC) / Zotye (STEC) / Ha/ma (STEC) / Maple (STEC) / Geely (SETC) /
•  Cherry (STEC) / Zhonghua230 / Zhonghua530 / VW46 (2007-2008) / X-Trail (2008-2009)
• Renault (Maste.II) / Renault (Trafic II) / Opel (Vivaro) / Opel (Movano) / Renault (Espace IV)
• Renault (Laguna II) / Renault (Velsatis) / Renault (Twingo) / Citroen / Fiat / Lancia / Peugeot (206/307)

Transponder Production coverage continued…

• Mitsubishi / Cruze / Siemens / Changhe / Suzuki / GM / Beidouxing
• T5 type: 11 / 12 / 13 / 33
• ID47 type: Honda
• Id63 ford 80 bit

Signal Test

•  Frequency Test (remote, ASK/FSK)
• ECU signal test (check if the coil works or not)

Simulator:
The KD X2 allows you to simulate the key before you clone it, to ensure working correctly prior to cloning a chip on ID46 and 4D

Transponder Edit:allows you to read, write and edit chip data on 4D / 46 / 48 / 47 / 4D DST/8A etc

KEYDIY KD X2 Key Programmer Support Car List:

• Audi ,Baojun ,Bcahy ,Benjin Auto,  Benz , Besturn , BMW , BYD , Cadillac , Chang an , Changfeng Motors , Changhe,
• Chevrolet ,  Chrysler , Citroen , Daihatsu , Dongfeng , Faw , Fiat , Ford , Garage ,  Geely ,  GMC ,Great Wall Automobile ,
• HaiMa , Hawtai Motor , Honda ,  Hyundai ,  Isuzu Iveco ,  Jaguar ,  Jianghua ,  Kia ,  Land Rover ,  Lincoln ,  Mahindra ,
• Mazda ,MG ,  Mitsubishi ,  Nissan , Opel , Peugeot  Citroen DS ,  Porsche ,Proton , Renault , Saipa , Samand ,  Seat ,Skoda ,
• Ssangyong ,  Subaru ,  TATA , Toyota for Lexus , Volvo, VW, Zhongxing

KEYDIY KD X2 Key Programmer Package :

1.  KEYDIY KD X2 Main Unit
2. USB Cable
3.  3pcs Commonly Remotes
4.  Remote Data Cable
5.  Spare Remote Data Cable
